Surround panning

When the PRO2 is configured to operate in one of the surround panning modes, the
spatial diagram that appears in the GUI channel strip gives you a visual representation
of the sound image in relation to the speakers.
The following diagram shows the appearance of the GUI channel strip for each panning
mode, and describes the controls.
1
3
Item
1
2
3
4
5
6
7
8
Although the position cursor changes automatically according to the adjustment
of the surround panning controls, you can also adjust it on the GUI using drag.
None
2
3
4
5
6
Description
SIS™ image
control knob
fb pan control
knob
Left-centre-right
(LCR) control knob
front control knob
front to back
control knob
back control knob
centre level
control knob
LFE level control
knob
Quad
2
3
4
5
6
7
Function
With SIS switched on, this adjusts the SIS™ image.
With SIS switched off, this adjusts the mono level.
Moves the position cursor in the spatial diagram
up/down. With SIS switched off, this adjusts the
mono level.
Moves the position cursor in spatial diagram
left/right.
Adjusts the divergence of the front speakers.
Adjusts the divergence of the front and rear
speakers.
Adjusts the divergence of the rear speakers.
Adjusts the divergence of the centre speaker.
Adjusts the signal level of the LFE (usually a
subwoofer).
