About the updater screen

During installation the updater screen will appear. This screen lets you select the
system devices you want to upgrade, start the update procedure and also shows you
how the procedure is progressing.
2
7
6
Figure 29: A typical updater display
Item
1
2
3
4
5
6
7
Appendix E: Updating The PRO2 Host Software
Description
Updater menu
Pointer
PRO2 host
software version
Unit Status
window
Device block
Update status bar
Device area
1
Function
See "Updater menu" on page 331.
The pointer, which has two possible icons (both
translucent yellow) depending on the update status,
changes to an arrowhead icon
ready for you to select the devices that you want to
update. The pointer becomes a roundel
during the update procedure; it rotates to show that
the update is in progress.
Shows the PRO2 host software version that the
system will be updated to.
See "Unit Status window" on page 331.
See "Device blocks" on page 331.
The green bar shows the progress of the update
procedure, whether it is for the device currently being
updated or for the whole procedure itself. The text
immediately above shows what status the green bar
is representing.
Shows possible/actual system devices.
3
4
5
when the updater is
icon
