Input metering

Input metering
The Console Overview screen shows all of the meters all of the time. Meters can be
switched globally to monitor the raw A/D input point, and are also individually
switchable using the meter CHECK button in the gain section (see "Mic amp input gain
(preliminary input processing)" on page 244).
3
2
6
4
1
5
3
2
6
Item
1
2
3
4
5
6
7
8
PRO2 Live Audio System
Owner's Manual
1
Description
11-segment meter for showing the input channel level
SOLO switch for switching the input channel's solo on/off
MUTE switch for muting the input channel
LED meter for showing the gain reduction when using a compressor
LED meter for showing the gain reduction when using a gate
Input channel fader
PRE switch, which is a global meter switch that switches all inputs to
monitor the raw A/D input point.
FLIP switch for enabling flip mode.
Channel meters
7 8
