About the GEQ window

About the GEQ window
In the centre of the GUI screen, the GEQ window shows the selected GEQ's front panel.
This gives you full control of the GEQ via the GUI controls in the navigation zone by
using the trackball and left and right buttons. Below the GEQ is an assignable
controls panel that lets you select and control the GEQ faders (singly or in groups) and
the controls on the right.
9
8
7
GEQ window
Item
1
2
3
4
5
6
7
8
9
>> To open a GEQ unit window
In the Graphic EQs screen, click on a non-control area of the unit you want.
PRO2 Live Audio System
Owner's Manual
1 2
Element Description
COPY button Copy and paste function button (see Chapter
18 "Copy And Paste" on page 185).
PASTE button Copy and paste function button (see Chapter
18 "Copy And Paste" on page 185).
FLAT button Sets all of the GEQ's faders to 0dB.
STORE PRESET See Chapter 24 "User Libraries (Presets)" on
button page 235.
LOAD PRESET See Chapter 24 "User Libraries (Presets)" on
button page 235.
CLOSE button Closes the GEQ window.
assignable See Chapter 19 "Assignable Controls (I Zone)" on
controls panel page 187.
GEQ panel Shows the front panel of the GEQ (see "GEQ front
panel features" on page 124.
Drop-down list For selecting the source of the GEQ.
3 4
6
123
5
