Matrices
EQ safe
The following diagram details the parameters in the matrices protected by the EQ safe,
and shows the EQ detail area in the GUI channel strip and the GEQ window on the GUI
screen.
Item
1
2
3
4
5*
6*
7
* Not shown in diagram.
Note: Although bands 1 and 2 are not shown above, the items in the table also apply.
Both bands have items 2, 3 and 4. Additionally, band 1 also has item 7, and band 2
also has item 6.
PRO2 Live Audio System
Owner's Manual
4 5/6/7
1
3
Control
EQ switch
gain control knob
width control knob
freq control knob
SHAPE switch
SHAPE switch
SHAPE switch
1
2
Parameter
EQ on/off
EQ gain level
EQ width
EQ frequency
Selects band 1 shelving modes: parametric,
warm, high pass 6dB or high pass 12dB
Selects band 2 shelving modes: parametric or high
pass 24dB
Selects band 6 shelving modes: parametric, soft,
low pass 6dB or low pass 12dB
413
4
2
3
4
2
3
4
6
2
3
4
5
2
3
