EQ (E zone)

Item
4
5
EQ (E zone)
The input channel equaliser (EQ) is a four-band swept parametric EQ (PEQ) that allows
tonal control of the input signal via the parametric EQ section, or E zone, in the input
channel strip. The four bands are treble, hi-mid, lo-mid and bass, with an additional
three shelving modes available for treble and bass. Any combination of the four bands
can be used to control the signal, although only one band can be adjusted in the E zone
at any time.
The E zone contains all of the PEQ controls, along with a shelving mode selection button
and a set of band selection buttons.
9
3
3
7
PRO2 Live Audio System
Owner's Manual
Description
Insert return field shows you the source of the insert return.
Insert send field has a drop-down list, which shows the destination(s) of the
insert return.
12
10
2
1
7
8
11
Treble and bass
shelving modes
3
4
E zone
5
4
4
5
4
6
3
2
257
