Dynamic EQ
Item
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
PRO2 Live Audio System
Owner's Manual
Element
MODE button
Band selection
indicator
Limit curve
Dynamic curve
IN button and LED
indicator
comp/exp meter
LSN button and
LED indicator
EQ type
Name field
WIDTH control
knob
FIXED button and
LED indicator
RATIO control
knob
FAST REL. button
and LED indicator
FREQ control knob
BELOW button
and LED indicator
THRESHOLD
control knob
Meter
Band I/O
Function
Selects the routing configuration. Audio routing
paths are illustrated by item 18.
Shows the selected routing configuration mode.
Shows the minimum cut/maximum boost EQ
response for the selected band.
Shows the real time dynamic EQ response curve.
This curve will vary between flat (no EQ) and the
outer curve (full EQ) depending on the signal level,
ratio and threshold settings.
Switches the individual band on/off.
Shows the current cut/boost of the selected EQ band.
Sidechain listen button that routes the bandpass
filtered sidechain signal to the unit output.
Selects the type of equaliser (shown in item 9) from
Bell, Low Shelf, High Shelf and Full Band.
Shows the currently selected EQ type.
Sets the bandwidth of the EQ band and sidechain
filter for the selected band.
Forces selected band to use a fixed EQ gain, so that
when it is enabled it behaves as a static EQ. This is
useful for previewing the effect of the EQ curve.
Sets the ratio of the compression or expansion
applied to the selected band. The centre position
produces a ratio of 1:1, which will have no effect. As
the control is turned anti-clockwise, more
compression is applied, up to a ratio of 25:1. If the
control is turned clockwise from the centre position,
expansion is gradually applied up to the ratio of 1:25.
Enables fast envelope release setting.
Sets the centre frequency of the selected EQ band.
Sets whether the compressor/expander operates
above (off) or below (on) the threshold (see
Figure 10 "Transfer characteristics" on page 142).
Sets the threshold level.
Shows the level of the sidechain signal relative to the
threshold setting, that is, it shows the signal level
within the frequency region selected by the frequency
(FREQ) and width (WIDTH) controls.
Shows the audio routing path between inputs,
outputs and the four EQ bands.
