Inputs

Inputs
Each scope screen has 56 input channels in the Input Channels section.
Routing (A)
All (B)
Mic Amp (C)
EQ (D)
Dyn (E)
Busses (F)
Mute (G)
Fader (H)
Figure 30: Parameter sections per input channel
Patching
The following diagram details the scoped patching parameters of the input channels,
and shows the configuration detail area in the GUI channel strip.
A
B
C
D
E
F
G
H
Item Parameter
1 Input patching source
* Includes tape return and primary input sources.
PRO2 Live Audio System
Owner's Manual
1
A B
Yes* Yes*
56 input channels
C D E
No N/A N/A
339
F G H
N/A N/A N/A
