Linking two mixes
You can link two mixes together, which is a GUI only feature. Pairs can only be created
from adjacent mix buses of the same colour, for example, you can link auxes 3 and 4
together, but not 2 and 3.
>> To route an aux or matrix to an effect or output
To link a pair of mix buses, click the
LINK button in the channel strip of
either mix bus. For example, click
LINK of aux 15 to link it to aux 16
(shown right).
Setting the linked parameter options
The shared parameters default to the user-configurable global
default link settings, which are set via the GUI menu (choose
home Preferences
However, you can override these for the pair via the Stereo
Linking Options window (shown right), which is opened by
clicking the st. linking options button (GUI channel strip).
In stereo mix mode the top control knob becomes pan adjust
and the bottom one adjusts level. When creating a stereo mix,
you can use either the odd or even output to link the two
channels, but the mode of the odd channel is used on both.
For details of the parameters that are stereo linked, see
Appendix J "Parameters Affected By Stereo Linking" on
page 461.
General and click the Linking tab).
