Midas PRO2 Owner's Manual page 330

312
PRO2 control surface - analogue audio system inputs
Connector
A/D converter
Talkback connector
Talk connector
Meters (11-off)
PRO2 control surface - analogue audio system outputs
Connector
D/A converter
Monitor connector
Talk connector
Headphone connector
Automation advance connector
Meters (24-off)
Meters (2-off)
PRO2 control surface - digital audio system inputs and outputs
Input connector
Sample rates
Bypass
Output connector
Sample rate
Bypass
Word length
PRO2 control surface - control data system inputs and outputs
System connector
Appendix C: Technical Specification
3-pin XLR balanced
24-bit, 96kHz and 128 times oversampling
3-pin XLR balanced line
3-pin XLR balanced mic with 48V phantom
voltage
10-segment, -36dBu to +21dBu
3-pin XLR balanced
24-bit, 96kHz and 128 times oversampling
3-pin XLR balanced line
3-pin XLR balanced line
1/4" Jack (stereo)
1/4" Jack (mono)
10-segment, -36dBu to +21dBu
20-segment, -36dBu to +21dBu
AES3 (two channels of digital audio) on 3-pin
XLR
Accepts any frequency 32kHz - 96kHz
Sample rate converter can be bypassed
AES3 (two channels of digital audio) on 3-pin
XLR
48k, 96k, or auto-tracking to inputs
Sample rate converter can be bypassed
16, 20 or 24-bit
EtherCon® XLR
