Above Threshold Compression
( Below = off, Ratio = comp )
Output
Level
Below Threshold Compression
( Below = on, Ratio = comp )
Output
Level
Figure 10: Transfer characteristics
Input
threshold Level
Input
threshold
Level
Chapter 16: Internal Effects
Above Threshold Expansion
( Below = off, Ratio = exp )
Output
Level
threshold
Below Threshold Expansion
( Below = on, Ratio = exp )
Output
Level
threshold
PRO2 Live Audio System
Input
Level
Input
Level
