Mixing control assistance
Resilience

PRO2 general specifications

Sampling frequency
Latency delay
Dynamic range
Maximum voltage gain
Crosstalk at 1kHz
Crosstalk at 10kHz
Fader/pan cut off at 1kHz
Fader/pan cut off at 10kHz
Display screens
LCD switch
Motorised faders
Fader resolution
Encoders
Encoder resolution
Dimensions
Net weight*
Power requirements
Operating temperature range
Storage temperature range
* Weights are approximate and out of flight case.
Appendix C: Technical Specification
6 x auto-mutes
6 x surface POPulation groups
8 x VCA faders
8 x VCA associated POPulation groups
176 x MCA faders
176 x flipped MCA POPulation groups
1000-scene snapshot automation
N+1 cable redundancy and dual redundant
PSUs
96kHz
<2ms input to master (no compensation)
106dB, 22Hz to 22kHz (no pre-emphasis)
80dB inputs to subgroups and masters
86dB inputs to aux and matrix
-100dB physically adjacent input channels
-90dB physically adjacent input channels
-100dB
-100dB
1 x 15" daylight-viewable colour screen
25 x RGB colour
20 x touch-sensitive
1024 steps
31 x touch-sensitive
512 steps
PRO2 control centre: 1179.6 mm wide x
730.3 mm deep (46.44" x 27.75")
PRO2C control centre: 882 mm wide x
730.3 mm deep (34.72" x 28.75")
DL251 I/O box: 5U x 200 mm deep
PRO2 control centre: 40 kg
PRO2C control centre: 37 kg
1 x DL2531: 10 kg
100V to 240V a.c. ±10%, 50 to 60Hz
+5°C to +45°C
-20°C to +60°C
