Input Channels
Bus sends
The following diagram shows the input bus sends affected by stereo linking, and applies
to the 16 auxes and eight matrices.
1
2
3
1
2
3
Note: Only matrix sends 1 to 8 are shown above, but this is typically the same for all of
the bus sends (eight matrices and 16 auxes).
Item
1
2
3
4
PRO2 Live Audio System
Owner's Manual
5
6
As per bus sends 1-2
above
Control
ON switch
level/pan control
knob
PRE switch
level control knob
Parameter
Bus send on/off
Bus level, or pan when bus is linked. (When
sending onto a stereo bus the send pan controls
are not linked.)
Pre-fader on/off
Bus level
469
1
2
3
1
4
3
As per
bus sends
1-2 above
