Typical configurations
Monitor Mix
The following table shows the delay compensation settings for this mix.
Option
Master to Matrix Post-processing
Input Channels
Insert
Aux Sends
Monitor Mode (Align with Masters)
Insert
Send-FX-Return
Graphic EQ
Master and Matrix
Insert
Graphic EQ
The following example signal paths all measure the same latency of 300 samples @
96kHz = 3.125 ms:
• FOH XLR – IP – MAST – XLR
• XLR – IP – MAST – XLR
• XLR – IP – MTX – XLR
• XLR – IP – MAST- MTX – XLR
• XLR – IP – AS – XLR
• XLR – IP – AS (With GEQ) – XLR
• XLR – AS DI – AS – XLR
• XLR – AS DI – AS (With GEQ) – XLR
• XLR – AR (Input) – MAST – XLR
• XLR – AR (Input) – MAST (With GEQ) – XLR
• XLR – AR (Input) – MTX (With GEQ) – XLR
• XLR – AR (Input) – MAST - MTX - XLR
• XLR – AR (Input) – MAST - MTX (With GEQ) - XLR
PRO2 Live Audio System
Owner's Manual
On/off status
Off
Off
On
On
Off
On
On
On
223
