Output channel configuration controls

Item
4
5
6
7
8
Output channel configuration controls
There are a number of output channel controls that are loosely termed 'channel
configuration' controls. The following table shows the configuration controls available
on each output and references the pertinent section within this chapter.
Table 13: Output channel configuration controls
Channel controls
Output channel ID
Output channel
source/destination
Stereo linking
Mix
Link fader
Bus trim
Direct input
Safes (EQ,
dynamics, mic,
auto, mute and
fader)
Insert
Delay
Processing order
PRO2 Live Audio System
Owner's Manual
Description
FADER/[FDR] switch, switches fader safe on so that the fader is removed
from scene recall.
MUTE/[MTE] switch, switches mute safe on so that mute is removed from
the scene recall and auto-mute action.
AUTO/[AUT] switch, switches auto safe on so that the channel is removed
from scene recall (this does not affect the action of the auto-mutes and VCA
control groups) and control is removed from VCA control group faders.
Fader for adjusting output signal level. Has the same function as the level
control knob (see item 3).
Solo B switch (GUI only), changes the operation of the SOLO switch so that
it routes signals to the Monitor B section of the control centre.
Aux
Yes
Destination
Yes
Yes
N/A
Yes
Yes
All six
Yes
Yes
Yes
Matrix Master
Yes Yes
Destination Destination
Yes Yes
N/A N/A
Yes N/A
Yes Yes
Yes Yes
All six All six
Yes Yes
Yes Yes
Yes Yes
279
Refer to
Page 280
Page 280
Page 280
Page 280
Page 280
Page 280
Page 281
Page 281
Page 281
Page 281
Page 281
