PRO2 system inputs and outputs

PRO2 system inputs and outputs
DL251 I/O box - analogue inputs
Connector
A/D converter
DL251 I/O box - analogue outputs
Connector
D/A converter
DL251 I/O box - MIDI
MIDI
DL251 I/O box - digital system inputs and outputs
System connector
N+1 connector
PRO2 control surface - DSP/router system inputs and outputs
System connector
N+1 connector
System expansion connector
Word clock IN connector
Word clock OUT connector
AES3 sync IN connector
AES3 sync OUT connector
PRO2 Live Audio System
Owner's Manual
3-pin XLR balanced
24-bit, 96kHz and 128 times oversampling
3-pin XLR balanced
24-bit, 96kHz and 128 times oversampling
In, Out and Thru on 5-pin DIN
2 x AES50 (24 channels of bi-directional digital
audio) on EtherCon® XLR
1 x AES50 (24 channels of bi-directional digital
audio) on EtherCon® XLR providing redundant
back-up
2 x AES50 (24 channels of bi-directional digital
audio) on EtherCon® XLR
1 x AES50 (24 channels of bi-directional digital
audio) on EtherCon® XLR providing redundant
back-up
3 x AES50 (24 channels of bi-directional digital
audio) on EtherCon® XLR
BNC
BNC
3-pin XLR
3-pin XLR
311
