Mic amp input gain (preliminary input processing)
Mic amp input gain on the control surface and GUI
Item
1
2
3
4
PRO2 Live Audio System
Owner's Manual
5
6/14
4
9
12
10
11
15
DL251
Control
48V switch (stage
box only)
TALK switch
Gain swap button
SLOPE switch
(digital trim only)
2
1
13
13
DL351
Function
Connects 48 volts of phantom power to the XLR mic
input channel connector. Suitable for a condenser
microphone or DI box.
Connects talk mic and/or tone and noise generators
to the input channel.
See "Using gain swap" on page 247.
Selects the value of the high pass filter. Where,
switch on (illuminated) = 24dB slope and switch off
(extinguished) = 12dB slope.
