216
To avoid the comb filtering effect, the PRO2 insert compensation works by delaying all
channels except the ones that have inserts assigned. In practice, the actual delay used
for compensation depends on the type of insert (internal/external) and its location
(stage/FOH). Each channel type or layer within the console, such as, input, aux,
master or matrix, has its own parameter controlling the delay compensation for that
layer. This provides the user with the maximum flexibility and allows the console to be
configured for the lowest latency for a given application.

GEQ compensation

Output bus channels have the ability to have a GEQ inserted into them, which incurs an
additional delay in their signal path. With GEQ compensation active, a delay is inserted
into the output buses, which is removed when a GEQ becomes active. This ensures
that all bus outputs of the same type are aligned regardless of whether they use a GEQ
or not.

GUI Delay Compensation options

PRO2 delay compensation (latency) is configured in the
Delay Compensation section (shown right) of the Delay
Compensation screen.
For a description of the delay compensation options and
details of when best to use them, see Table 11 (below). In
this table the Description column explains what happens
when the delay compensation option is selected (switched
on) and the Latency (ms) column shows the value that
the overall system latency is increased by.
>> To access the delay compensation options
At the GUI, choose home
click the Delay Compensation tab to open the
Preferences Delay screen.
Table 11: Delay compensation options
Section Option
Input Insert
Channels
Aux Monitor
Sends Mode
(Align
with
Masters)
Chapter 28: Delay Compensation (Latency)
Preferences
Description
Time-aligns the output of all
input channels, regardless of
whether or not they have an
active insert. When this
option is switched off, any
input channels with inserts
will be delayed relative to
those input channels that do
not have inserts.
See "Monitor Mode (Align
with Masters)" on page 218.
General and
Recommendations
If no inserts are used in the
input channel layer, switch
this option off to reduce the
overall system latency.
If there is an insert on any
input channel, switch this
option on.
N/A
Latency
(ms)
0.84
N/A
