Chapter 14: Monitors And
Communications
This chapter describes the monitoring and communications functions of the PRO2.

Monitors (A and B)

To match the two-bus solo system there are two monitor outputs, A and B, which
control their respective output levels. These are controlled from the monitor section on
the master bay (see Figure 9 "Monitor A and B strips" on page 110). Each monitor
output has:
• The ability to monitor mono and stereo outputs, and an external input.
• An external talkback input.
• A local monitor output.
• A headphone output.
• Delay compensation.
• Control of the solo buses.
Although the capabilities of both monitors are the same, monitor A is the primary
output. They both have a fader control, and there are four balanced XLR outputs on the
rear panel (see "Monitor and outputs/surround section" on page 268).
The monitor output controls do not have support from the screens and are not affected
by automation.
The monitor a and monitor b meters monitor the peak signal levels of stereo left and
right for both monitor paths. The metering capabilities of both monitors is the same.
>> To switch control of headphones to fader
Press C/O.
