Midas PRO2 Owner's Manual page 461

Aux
Item
6
7*
* Not shown in diagram.
Note: Although bands 5 and 6 are not shown above, the items in the table also apply.
Both bands have items 2, 3 and 4, and band 6 also has item 7.
Item
1
2
3
4
5
6
7
8
9
10
11
12
13
PRO2 Live Audio System
Owner's Manual
Control
SHAPE switch
SHAPE switch
1
Control
31 faders
High pass filter control
knob
IN switch
Low pass filter control
knob
IN switch
EQ switch
SLOPE switch
Q switch
IN switch
Notch filter control
knob
IN switch
Notch filter control
knob
SLOPE switch
Parameter
Band 2 shelving mode: bell or high pass 24dB
Band 6 shelving mode: bell, soft, low pass 6dB or
low pass 12dB
13
Parameter
Fader positions
High pass filter cut off frequency
High pass filter in/out
Low pass filter cut off frequency
Low pass filter in/out
EQ in/out
Low pass filter: 6dB or 12dB
Q mode as proportional (PROP.) or constant
(CON.)
200Hz - 20kHz notch filter in/out
200Hz - 20kHz notch filter frequency
20Hz - 2kHz notch filter in/out
20Hz - 2kHz notch filter frequency
High pass filter: 6dB or 12dB
