Rear panel connections
Connectors in area B
Area B houses the connectors for mains power, USB devices, external monitor, etc.
External connections on the right rear panel of the control centre
Item
1
2
3
4
5
Ethernet control
A 100Mb/s Ethernet control port (on EtherCon®) lets you connect equipment, such as
the Klark Teknik DN9331 Rapide Graphic Controller.
PRO2 Live Audio System
Owner's Manual
5 5
Description
Ethernet control connector (see "Ethernet control" below).
control computer reset button. This recessed button is for service
personnel use only.
USB connectors (see "USBs" below).
Screen output connector (see "Screen output" on page 234).
Mains input connectors (see "Mains power connectors" on page 234).
233
1
2
3
4
