Rack unit number allocation
Each unit position in the rack is allocated a rack
number that is recognised by the PRO Series
Live Audio System (shown right).

About the effect window

Similarly to the GEQ window on the GUI, the effect window shows a screen-width
version of the selected effect, which gives you full control of the effect via the trackball
and left and right buttons in the navigation zone. A 'virtual' assignable controls panel
below lets you select and operate the controls of the effect.
7
6
5
Effect window
Item
1
2
3
4
5
1
Element Description
CHANGE DEVICE Lets you select a different effect.
TYPE button
STORE PRESET User library function button (see Chapter 24 "User
button Libraries (Presets)" on page 235).
LOAD PRESET User library function button (see Chapter 24 "User
button Libraries (Presets)" on page 235).
CLOSE button Closes the effect window.
assignable See Chapter 19 "Assignable Controls (I Zone)" on
controls panel page 187.
Chapter 16: Internal Effects
2
4
1
2
3
4
5
6
3
