Instruction Speed Summary; Table 6-23 Arm Instruction Speed Summary - ARM ARM7TDMI Technical Reference Manual

6.20

Instruction speed summary

ARM DDI 0210C
Because of the pipelined architecture of the CPU, instructions overlap considerably. In
a typical cycle, one instruction can be using the data path while the next is being
decoded and the one after that is being fetched. For this reason Table 6-23 presents the
incremental number of cycles required by an instruction, rather than the total number of
cycles for which the instruction uses part of the processor. Elapsed time, in cycles, for
a routine can be calculated from these figures listed in Table 6-23. These figures assume
that the instruction is actually executed. Unexecuted instructions take one cycle.
If the condition is not met then all instructions take one S-cycle. The cycle types N, S,
I, and C are described in Bus cycle types on page 3-4.
In Table 6-23:
• b is the number of cycles spent in the coprocessor busy-wait loop
• m is:
— 1 if bits [31:8] of the multiplier operand are all zero or one, else
— 2 if bits [31:16] of the multiplier operand are all zero or one, else
— 3 if bits [31:24] of the multiplier operand are all zero or all one, else
— 4.
• n is the number of words transferred.
Copyright © 2001, 2004 ARM Limited. All rights reserved.

Table 6-23 ARM instruction speed summary

Instruction Cycle count
Data Processing S
MSR, MRS S
LDR S+N+I
STR 2N
LDM nS+N+I
STM (n-1)S+2N
SWP S+2N+I
B,BL 2S+N
SWI, trap 2S+N
MUL S+mI
Instruction Cycle Timings
Additional
+I for SHIFT(Rs)
+S + N if R15 written
-
+S +N if R15 loaded
-
+S +N if R15 loaded
-
-
-
-
-
6-29
