Mounting the Collaboration Server 4000 in a Rack

Either place the RMX 4000 on a hard, flat surface such as a desktop or mount it on a 19" rack.
For a detailed description of the safety requirements and precautions and the installation of the
RMX 4000 as a standalone, or reverse mounting the RMX 4000 on a 19" rack, see the
RealPresence Collaboration Server (RMX) 4000 Hardware Guide.
To install the Collaboration Server 4000 in a 19"rack:
•
Refer to
RMX types" on page
•
1-16
Using rack rail runners on the RMX 4000
— Install the telescopic rail runners, as described in "Installing the Telescopic Rail
Runners on the Rack" on page 1-5.
— Mount the Collaboration Server 2000 on top of the rail runners.
— Fasten the Collaboration Server to the rack spacers using the flat head screw
(item 8) with flat washer
Server's front mounting brackets.
Figure 1-2, "Detail of Front Rack Spacer Assembly (left rail runner is shown here) for all
1-7 for installation instructions.
Using a shelf
— Install the shelf, supplied by the rack manufacturer, in the rack.
— Mount the Collaboration Server on the shelf.
(item 9) through the two holes in the Collaboration
