E General
e Frequency coverage
e Mode
e Number of memory :
channels
e Antenna impedance :
e Usable temperature :
range
e Frequency stability :
e Power supply
requirement
e Current drain
(at 13.8 V DC)
e Dimensions
e Weight
: Transmit —
SPECIFICATIONS
:Transmit*
1.8000 — 1.9999 MHz
3.5000 — 3.9999 MHz
7.0000 — 7.3000 MHz
10.1000 — 10.1500 MHz
14.0000 — 14.3500 MHz
18.0680 — 18.1680 MHz
21.0000 — 21.4500 MHz
24.8900 — 24.9900 MHz
28.0000 — 29.7000 MHz
*Permitted frequency range varies ac-
cording to country and your class.
Receive
500 kHz — 30 MHz
: SSB (USB/LSB), CW, AM, FM*
*An optional UI-9 FM UNIT is required.
Normal channels 25
Split channels 5
Scan edge channels 2
50 Q nominal
—10%T to +60°C; + 14°F to
+ 140°F
Less than +200 Hz
from 1 min. to 60 min. after power
(on. at +25°C; +77°F )
Less than +30 Hz/hr.
from 60 min. after power ON,
(ai +25; +77°F )
Less than +350 Hz
at temperature fluctuations
(or to +50; +32°F to +122)
: 13.8 V DC + 15%
20A
Receive squeliched 1.3A
max. audio output 2.1 A
:240(W) x 95(H) x 239(D) mm
9.4(W) x 3.7(H) x 9.4(D) in
(projections not included)
: 4.1 kg; 9.0 Ib
Wi Transmitter
e Output power
e Modulation system :
e Spurious emissions :
e Carrier suppression :
e Unwanted sideband :
e Microphone
impedance
E Receiver
e Sensitivity
< (preamp ON)
e Squelch sensitivity
(preamp OFF)
e Selectivity
e Spurious and image:
rejection ratio
e Audio output power :
e RIT variable range :
All stated specifications are subject to change without notice or obligation.
: SSB, CW, FM
5 -— 100 W
AM 5- 25W
Balanced modulation
Low power modulation
Variable reactance
frequency modulation
50 dB below peak output power
More than 40 dB
More than 50 dB
: 600 Q
:0.5 — 1.8 MHz AM
Less than 13 uV for 10 dB S/N
1.8 — 30 MHz SSB, CW
Less than 0.16 pV for 10 dB S/N
1.8 — 30MHz AM
Less than 2.0 pV for 10 dB S/N
28 — 29.7 MHz FM
Less than 0.5 pV for 12 dB
SINAD
: SSB, CW Less than 5.6 uV
FM Less than 1.0 uV
: SSB, CW
More than 2.1 kHz/—6 dB
Less than 4.0 kHz/— 60 dB
AM
More than 6.0 kHz/—6 dB
Less than 20.0 kHz/— 40 dB
FM
More than 12 kHz/—6 dB
Less than 30 kHz/— 50 dB
More than 70 dB
More than 2.6 W with an 8 Q load
+1.2 kHz
