C
ONFIGURING THE
Web – Click VLAN, Private VLAN, Port Information or Trunk
Information.
CLI – This example shows the switch configured with primary VLAN 5
and secondary VLAN 6. Port 3 has been configured as a promiscuous port
and mapped to VLAN 5, while ports 4 and 5 have been configured as host
ports and associated with VLAN 6. This means that traffic for port 4 and 5
can only pass through port 3.
Console#show vlan private-vlan
Primary
--------
5
5
Console#

Configuring Private VLAN Interfaces

Use the Private VLAN Port Configuration and Private VLAN Trunk
Configuration menus to set the private VLAN interface type, and associate
the interfaces with a private VLAN.
2-128
S
WITCH
Secondary
----------- ----------
primary
6 community
Type Interfaces
------------------------------
Eth1/ 3
Eth1/ 4 Eth1/ 5
3-137
