Goodrive390L Series Lift-Dedicated VFD
Item
Communication
PG card expansion Supports incremental, sin/cos, Endat, and SSI PG cards
Mounting method
Cooling method
Temperature of
Environment
Storage temperature -30–+60℃
requirements
Ingress protection
and
certificatio
Pollution degree
Applicable grid type TN or TT type
Protective class

2.3 Product ratings

Model
GD390L-2R2G-S2
GD390L-2R2G-2
GD390L-004G-2
GD390L-5R5G-2
GD390L-7R5G-2
GD390L-011G-2
GD390L-015G-2
GD390L-018G-2
202403 (V1.0）
Ten regular inputs. Max. frequency: 1KHz; internal
Digital input
impedance 3.3kΩ
Digital output One Y terminal open collector output
Three programmable relay outputs.
RO1A: NO; RO1B: NC; RO1C: common;
Relay output
Two groups of NO output: RO2A, RO2C; RO3A, RO3C NO;
Contact capacity: 3A/AC250V, 1A/DC30V
One CANopen and one RS485
interface
STO input Two redundant inputs, SIL3 level
One output. Resolution rate: 1°C; range: -20°C – +150°C;
PT100 input
detection accuracy: ±3°C
Supports 5V/12V incremental encoder (Select power
Encoder input
supply through the jumper. Default: 12V)
Wall mounting
Forced air cooling
-10°C – +50°C. Derating is required when the ambient
running
temperature exceeds 40°C.
environment
IP20
(IP) rating
PD2
Class I
Certification CE (with STO)
Voltage class
Single phase
230V
3PH 230V
Specifications
Output power
(kW)
2.2
2.2
4
5.5
7.5
11
15
18.5
Input current Output current
(A)
24
12
21
30
38
52
65
78
Product overview
(A)
10
10
18.5
27
34
48
60
75
