Goodrive390L Series Lift-Dedicated VFD
Function
Closed-loop setting
Closed-loop feedback
Input IO status
Output IO status
Analog input 1
Analog input 2
Analog input 3
Analog input 4
Read input of HDIA
high-speed pulse
Read input of HDIB
high-speed pulse
Read the actual step of
multi-step speed
External length value
External counting
value
Torque setting
VFD identification
code
Fault code
The Read/Write (R/W) characteristics indicate whether a function parameter can be read
and written. For example, "Communication-based control command" can be written,
and therefore the command code 06H is used to control the VFD. The R characteristic
indicates that a function parameter can only be read, and W indicates that a function
parameter can only be written.
Note: Some parameters in the preceding table are valid only after they are enabled. For
example, for the running or stop operation, you must set "Channel of running
commands" (P00.01) to "Communication", and set "Communication channel of running
commands" (P00.02) to "Modbus".
7.1.2.6 Fieldbus scale
In practical applications, communication data is represented in the hexadecimal form,
but hexadecimal values cannot represent decimals. For example, 50.12 Hz cannot be
202403 (V1.0）
Address
3008H -100.0–100.0% (Unit: 0.1%)
3009H -100.0–100.0% (Unit: 0.1%)
0x00–0x3F
300AH Corresponding to the local
S10/S9/S8/S7/S6/S5/S4/S3/S2/S1
0x00–0x0F
300BH (corresponding to local
RO3/RO2/RO1/Y1)
300CH 0.00–10.00V (Unit: 0.01V)
300DH 0.00–10.00V (Unit: 0.01V)
300EH -10.00–10.00V (Unit: 0.01V)
300FH
3010H 0.00–50.00kHz (Unit: 0.01Hz)
3011H
3012H 0–15
3013H 0–65535
3014H 0–65535
3015H -300.0–300.0% (Unit: 0.1%)
3016H
5000H
Communication protocol
Data description R/W
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
