Goodrive390L Series Lift-Dedicated VFD
Function
VFD status word 1
VFD status word 2
VFD fault code
VFD identification
code
Running frequency
Set frequency
Bus voltage
Output voltage
Output current
Rotational speed
Output power
Output torque
202403 (V1.0）
Address
(0–1000, in which 1000 corresponds to 100.0% of
the motor rated voltage)
AO setting 1 (-1000–+1000, in which 1000
200DH
corresponds to 100.0%)
AO setting 2 (-1000–+1000, in which 1000
200EH
corresponds to 100.0%)
0001H: Forward running
0002H: Reverse running
0003H: Stopped
2100H
0004H: VFD in fault
0005H: POFF
0006H: Pre-exciting
Bit0: =0: Not ready to run =1: Ready to run
Bit1–2=00: Motor 1
Bit3: =0: AM
Bit4: = 0: No pre-alarm upon overload
=1: overload pre-alarm
Bit5–Bit6=00: Keypad-based control
2101H =10: Communication-based control
Bit 7: Reserved
Bit8=0: Speed control =1: Torque control
Bit9=0: Non position control
=1: Position control
Bit10–Bit11: =0: Vector 0
2102H See the description of fault types.
2103H GD390L-----0x2701
3000H 0–Fmax (Unit: 0.01Hz)
3001H 0–Fmax (Unit: 0.01Hz)
3002H 0.0–2000.0V (Unit: 0.1V)
3003H 0–1200V (Unit: 1V)
3004H 0.0–3000.0A (Unit: 0.1A)
3005H 0–65535 (Unit: 1rpm)
3006H -300.0–300.0% (Unit: 0.1%)
3007H -250.0–250.0% (Unit: 0.1%)
Data description
=01: Motor 2
=1: SM
=01: Terminal-based control
=1: Vector 1
=2: Closed-loop vector
= 3: Space voltage vector
Communication protocol
R/W
R/W
R/W
Compatible
with CHF100A
and CHV100
communication
addresses
R
R
R
R
R
R
R
R
R
R
R
R
