Goodrive390L Series Lift-Dedicated VFD
Group P16—Communication expansion card 2 functions
Function
code
P16.00–
P16.01
Ethernet monitoring
P16.02
card IP address 1
Ethernet monitoring
P16.03
card IP address 2
Ethernet monitoring
P16.04
card IP address 3
Ethernet monitoring
P16.05
card IP address 4
Ethernet monitoring
P16.06
card subnet mask 1
Ethernet monitoring
P16.07
card subnet mask 2
Ethernet monitoring
P16.08
card subnet mask 3
Ethernet monitoring
P16.09
card subnet mask 4
Ethernet monitoring
P16.10
card gateway 1
Ethernet monitoring
P16.11
card gateway 2
Ethernet monitoring
P16.12
card gateway 3
Ethernet monitoring
P16.13
card gateway 4
Ethernet card
P16.14 monitoring variable
Ethernet card
P16.15 monitoring variable
Ethernet card
P16.16 monitoring variable
202403 (V1.0）
Name
Reserved -
Setting range: 0–255
Setting range: 0–255
Setting range: 0–255
Setting range: 0–255
Setting range: 0–255
Setting range: 0–255
Setting range: 0–255
Setting range: 0–255
Setting range: 0–255
Setting range: 0–255
Setting range: 0–255
Setting range: 0–255
Setting range: 0x0000–0xFFFF
address 1
Setting range: 0x0000–0xFFFF
address 2
Setting range: 0x0000–0xFFFF
address 3
Description
Function parameter list
Default Modify
- -
192 ◎
168 ◎
28 ◎
11 ◎
255 ◎
255 ◎
255 ◎
0 ◎
192 ◎
168 ◎
28 ◎
11 ◎
0x0000 ○
0x0000 ○
0x0000 ○
198
