INVT Goodrive390L Series User Manual page 183

Goodrive390L Series Lift-Dedicated VFD
Function
code
VFD electricity
P07.16
consumption LSB
P07.17 VFD model
P07.18 VFD rated power
P07.19 VFD rated voltage
P07.20 VFD rated current
P07.21 Factory bar code 1
P07.22 Factory bar code 2
P07.23 Factory bar code 3
202403 (V1.0）
Name
× 1000 +
Setting range: 0–65535kWh (*1000)
The function code is used to display
the electricity consumption of the
VFD.
VFD electricity consumption =
× 1000 +
Setting range: 0.0–999.9kWh
Setting range: 0x0000–0xFFF1
bit0–bit3: G type or P type
0x0: G type
0x1: P type
bit4–bit11:
manufacturer
0x00: DSP(TI)
0x01–0x20: Reserved
0x21: MCU(ST)
0x22–0xFF: Reserved
bit12–bit15: VFD series
0x0: GD390L
0x1–0xF: Reserved
Note: bit4–bit8 indicate the chip
manufacturer (such as TI, ST), while
bit9–bit11 indicate the chip type
(such as DSP, MCU).
Setting range: 0.4–3000.0kW
Setting range: 50–1200V
Setting range: 0.1–6000.0A
Setting range: 0x0000–0xFFFF
Setting range: 0x0000–0xFFFF
Setting range: 0x0000–0xFFFF
Description
P07.16
P07.16
Chip type
Function parameter list
Default Modify
0.0kWh
P07.15
and
0x0000
Model
depended
Model
depended
Model
depended
Model
depended
Model
depended
Model
depended
●
●
●
●
●
●
●
●
175
