Goodrive390L Series Lift-Dedicated VFD
Function
code
P97.12–
P97.20
Group P98—AIAO calibration function
Function
code
Calibration parameter
P98.00
group password
AD sampling value of AI1
P98.01
voltage input
P98.02 AI1 reference voltage 1 Setting range: -0.50–4.00V
AD sampling value
P98.03 corresponding to AI1
reference voltage 1
P98.04 AI1 reference voltage 2 Setting range: 6.00–10.50V
AD sampling value
P98.05 corresponding to AI1
reference voltage 2
AD sampling value of AI1
P98.06
current input
P98.07 AI1 reference current 1 Setting range: -1.00–8.00mA
AD sampling value
P98.08 corresponding to AI1
reference current 1
P98.09 AI1 reference current 2 Setting range: 12.00–21.00mA
AD sampling value
P98.10 corresponding to AI1
reference current 2
Sampling value of AI2
P98.11
voltage input
P98.12 AI2 reference voltage 1 Setting range: -0.50–4.00V
P98.13 AD sampling value
202403 (V1.0）
Name
1: Calibrate PT100 temperature
lower limit
2: Calibrate PT100 temperature
upper limit
Reserved -
Name
Setting range: 0–65535
Setting range: 0–4095
Setting range: 0–4095
Setting range: 0–4095
Setting range: 0–4095
Setting range: 0–4095
Setting range: 0–4095
Setting range: 0–4095
Setting range: 0–4095
Description
Description
Function parameter list
Default Modify
- -
Default Modify
***** ○
0 ●
0.00V ○
0 ○
10.00V ○
3972 ○
0 ●
0.00mA ○
0 ○
20.00mA ○
3903 ○
0 ●
0.00V ○
136 ○
212
