Goodrive390L Series Lift-Dedicated VFD
Function
code
P17.08 Motor power
P17.09 Motor output torque
Estimated motor
P17.10
P17.11 DC bus voltage
Digital input terminal
P17.12
Digital output terminal
P17.13
202403 (V1.0）
Name
the present exciting current of the
VFD.
Setting range: -3000.0–3000.0A
The function code is used to display
the present motor power. 100%
corresponds to the rated motor
power.
Setting Range: -300.0–300.0% (of the
rated motor power)
Displays the present output torque
of the VFD. 100% corresponds to the
motor rated torque.
Setting range: -250.0–250.0%
Used to indicate the estimated
motor rotor frequency under the
frequency open-loop vector condition.
Setting range:
Displays the present DC bus voltage
of the VFD.
Setting range: 0.0–2000.0V
Displays the present digital input
terminal state of the VFD.
Setting range: 0x000–0x3FF
bit0: S1
bit1: S2
bit2: S3
bit3: S4
state
bit4: S5
bit5: S6
bit6: S7
bit7: S8
bit8: S9
bit9: S10
Displays the present digital output
terminal state of the VFD.
state Setting range: 0x00–0x0F
bit0: Y1
Description
0.00–P00.03
Function parameter list
Default Modify
0.0% ●
0.0% ●
0.00Hz ●
0.0V ●
0x000 ●
0x00 ●
