Goodrive390L Series Lift-Dedicated VFD
Function
code
Starting frequency of
P01.09
DC braking for stop
DC braking current for
P01.10
P01.15 Stop inflection speed
P02.00
P02.01 Rated power of AM
P02.02 Rated frequency of AM
P02.03 Rated speed of AM
P02.04 Rated voltage of AM
P02.05 Rated current of AM
Group P03 Vector control group
P05.01 Function of S1
P05.02 Function of S2
P05.03 Function of S3
P05.04 Function of S4
P05.05 Function of S5
P05.06 Function of S6
P05.07 Function of S7
P05.08 Function of S8
P05.09 Function of S9
P05.10 Function of S10
P05.37 AI1 lower limit
Corresponding setting
P05.38
of AI1 lower limit
202403 (V1.0）
Recommended
Name
stop
Motor type
value
0.2Hz
80%
Generally, the speed is consistent with
the leveling speed. It is usually used to
0.000m/s switch the stop curve. After the speed
decreases to this point, the stop
curves switches to the stop S curve.
Actual motor
type
Traction
machine
nameplate
Traction
machine
nameplate
Based
Traction
nameplate
machine
nameplate
Traction
machine
nameplate
Traction
machine
nameplate
Default value Adjust according to the running effect
1 Up running (FWD)
2 Down running (REV)
8 Multi-step speed terminal 1 (MS1)
9 Multi-step speed terminal 2 (MS2)
10 Multi-step speed terminal 3 (MS3)
19 VFD enabling (ENA)
17 Contactor feedback (TB)
18 Brake feedback (FB)
3 Maintenance (EXM)
6 Fault reset (RET)
0.00V
Adjust according to actual needs
0.0%
Commissioning guidelines
Remarks
on the traction machine
