Goodrive390L Series Lift-Dedicated VFD
Function
code
S-curve ACC start
P10.38
segment duration
S-curve ACC end
P10.39
segment duration
P10.40
S-curve DEC start
P10.41
segment duration
S-curve DEC end
P10.42
segment duration
P10.43
S-curve start segment
P10.44
duration during stop
S-curve end segment
P10.45
duration during stop
Running speed at
P10.46
maintenance
ACC/DEC time at
P10.47
maintenance
DEC time for creeping
P10.53
Encoder type
P20.00
Encoder pulse
P20.01
P20.02 Encoder direction
Note: In multi-step speed running mode, multi-step speed 0 must be set to zero speed.
The timing diagram for open-loop running without an encoder is as follows (use the lift
upward running as an example).
202403 (V1.0）
Name Recommended value
2.0s
2.0s
ACC time 2.0s
2.0s
2.0s
DEC time 2.0s
2.0s
2.0s
0.200m/s
4.0s
2.0s
to stop
selection
Determined
type/pulse quantity
number
0
Commissioning guidelines
Set the value according to the
onsite commissioning.
encoder
Based on the encoder used
Modified according to the
commissioning result
Remarks
