Goodrive390L Series Lift-Dedicated VFD
VFD model
GD390L-7R5G-2
GD390L-011G-2
GD390L-015G-2
GD390L-018G-2
GD390L-004G-4
GD390L-5R5G-4
GD390L-7R5G-4
GD390L-011G-4
GD390L-015G-4
GD390L-018G-4
GD390L-022G-4
GD390L-030G-4
GD390L-037G-4
Note: The rated input voltage drop of input reactors is 2%. The rated output voltage
drop of output reactors is 1%.
E.3.2 Filter
A filter is used to prevent the surrounding interference and prevent the interference from
the VFD during running. GD390L series product includes models with built-in C2 filters
and models with C3 filters (see section
on C2, C3 models). The "EMC" screw has been installed in the factory to meet the
requirements of the corresponding class of IEC 61800-3 (the length requirements of
motor cables are detailed in the section
Remove the "EMC" screw in the following situations:
 The EMC filter is applicable to the neutral-grounded grid system. If it is used for the IT
grid system (that is, non-neutral grounded grid system), remove the "EMC" screw.
 If leakage protection occurs during configuration of a residual-current circuit breaker,
remove the "EMC" screw.
202403 (V1.0）
Input reactor
ACL2-015-4
ACL2-022-4
ACL2-030-4
ACL2-037-4
ACL2-004-4
ACL2-5R5G-4
ACL2-7R5-4
ACL2-011-4
ACL2-015-4
ACL2-018-4
ACL2-022-4
ACL2-030-4
ACL2-037-4
2.1 Product nameplate and model
C.3.1 EMC compatibility and motor cable
Peripheral accessories
Output reactor
OCL2-015-4
OCL2-022-4
OCL2-030-4
OCL2-037-4
OCL2-004-4
OCL2-5R5G-4
OCL2-7R5-4
OCL2-011-4
OCL2-015-4
OCL2-018-4
OCL2-022-4
OCL2-030-4
OCL2-037-4
for descriptions
length).
