Group P14—Serial communication
Function
code
Local communication
P14.00
Communication baud
P14.01
rate setting
202403 (V1.0）
Name
Setting range: 1–100Hz
Reserved -
Name
Setting range: 1–247
When the master writes the slave
communication address to 0
indicating a broadcast address in a
frame, all the salves on the Modbus
bus receive the frame but do not
respond to it.
address
The communication addresses on
the communication network are
unique, which is the basis of the
point-to-point communication.
set to 0.
The function code is used to set the
data transmission speed between
the host controller and the VFD.
Setting range: 0–7
0: 1200bps
1: 2400bps
2: 4800bps
3: 9600bps
4: 19200bps
5: 38400bps
6: 57600bps
7: 115200bps
VFD must be consistent with that on
the host controller. Otherwise, the
Description
Description
Note: The slave address cannot be
Note: The baud rate set on the
Function parameter list
Default Modify
1 Hz ○
- -
Default Modify
1 ○
4 ○
