Group P05—Input terminals
Function
code
P05.00
P05.01 Function of S1
P05.02 Function of S2
P05.03 Function of S3
P05.04 Function of S4
P05.05 Function of S5
P05.06 Function of S6
P05.07 Function of S7
P05.08 Function of S8
P05.09 Function of S9
P05.10 Function of S10
P05.11
P05.12
P05.13 Input terminal polarity
202403 (V1.0）
Name
Reserved -
Setting range: 0–40
0: No function
1: Up running (FWD)
2: Down running (REV)
3: Running in inspection (EXM)
4: Emergency operation (EMER)
5: Coast to stop (FSTP)
6: Fault reset (RET)
7: External fault (EF)
8: Multi-step speed terminal 1 (MS1)
9: Multi-step speed terminal 2 (MS2)
10: Multi-step speed terminal 3
(MS3)
11: Up forced DEC 1 (UFS1)
12: Up forced DEC 2 (UFS2)
13: Up forced DEC 3 (UFS3)
14: Down forced DEC 1 (DFS1)
15: Down forced DEC 2 (DFS2)
16: Down forced DEC 3 (DFS3)
17: Contactor feedback signal (TB)
18: Brake feedback signal (FB)
19: VFD enabling (ENA)
20: Forced decelerate to stop
21: Emergency mode
22: Motor overheating
23:
disconnected (for India)
24: UPS input disconnected by main
control (for India)
25: Base lockout
26–40: Reserved
Reserved -
Reserved -
The function code is used to set the
polarity of the input terminal.
Description
Main power supply
Function parameter list
Default Modify
-
1
2
8
9
10
0
0
0
0
0
input
-
-
0x000
-
◎
◎
◎
◎
◎
◎
◎
◎
◎
◎
-
-
○
