Goodrive390L Series Lift-Dedicated VFD
D.1 VFD overall dimensions
Figure D-1 Mounting dimensions diagram for 2.2–15kW VFD models
H1
Table D-1 Dimensions and mounting hole size of 2.2–15kW VFD models
VFD model
GD390L-2R2G-2
GD390L-2R2G-S2
GD390L-004G-2
GD390L-004G-4
GD390L-5R5G-4
GD390L-7R5G-4
GD390L-5R5G-2
GD390L-7R5G-2
GD390L-011G-4
GD390L-015G-4
202403 (V1.0）

Appendix D Dimension drawings

W1
W2
Outline dimensions (mm)
W1 H1
200.0 347.0
200.0 347.0
200.0 347.0
200.0 347.0
200.0 347.0
200.0 347.0
200.0 347.0
200.0 347.0
200.0 347.0
200.0 347.0
d
H2
dimensions (mm)
D1 D2
190.0 185.4 150.0
190.0 185.4 150.0
190.0 185.4 150.0
190.0 185.4 150.0
190.0 185.4 150.0
190.0 185.4 150.0
197.5 192.9 150.0
197.5 192.9 150.0
197.5 192.9 150.0
197.5 192.9 150.0
Dimension drawings
D1
D2
Installation Mounting
diameter d
W2 H2
334.5
334.5
334.5
334.5
334.5
334.5
334.5
334.5
334.5
334.5
hole
(mm)
Ø6
Ø6
Ø6
Ø6
Ø6
Ø6
Ø6
Ø6
Ø6
Ø6
143
