or set P00.13=1.
Note: For SMs, swapping the motor cables requires the motor parameter autotuning
(pole angle) again. It is recommended to set P00.13 to change the running direction of
the lift.

6.4.3 Adjusting the S curve for normal running

Before normal running, check that the control logic is correct and wiring is correct. After
these are confirmed to be correct, adjust the S curve. For details, see the descriptions of
P10.38–P10.45.
Function
code
P01.01
P01.03
P01.15
P10.38
P10.39
P10.40
P10.41
P10.42
P10.43
P10.44 S-curve start segment duration during stop
P10.45 S-curve end segment duration during stop
P10.53
P10.38–P10.45 determine the shape of S curve. The S-curve quality directly impacts the
comfortability of the lift at startup or stop. The S-cure parameters are listed in the above
table. The following figure describes the relationship between these parameters and
S-curve.
Frq
P01.01
202403 (V1.0）
Name
Starting speed of direct start
Hold time of starting frequency
Stop inflection speed
S-curve ACC start segment duration
S-curve ACC end segment duration
ACC time
S-curve DEC start segment duration
S-curve DEC end segment duration
DEC time
DEC time for creeping to stop
Figure 6-5 S-curve running
P10.40 P10.39
P01.03 P10.38
Commissioning guidelines
Setting range and
default value
0.000–P00.06 [0.000m/s]
0.0–50.0 [0.0s]
0.000–P00.06 [0.000m/s]
0.1–360.0 [2.0s]
0.1–360.0 [2.0s]
0.1–360.0 [2.0s]
0.1–360.0 [2.0s]
0.1–360.0 [2.0s]
0.1–360.0 [2.0s]
0.1–360.0 [2.0s]
0.1–360.0 [2.0s]
0.1–360.0 [2.0s]
P10.41 P10.43
P10.42 P10.44
P10.53
P10.45
t
