Goodrive390L Series Lift-Dedicated VFD
Note:
The PG card does not internally connect the PE to the earth, and you need to connect

PE to the earth during use.
The absolute encoder PG card have the similar output signal wiring method as the

incremental encoder PG card, but they do not support push-pull output.
202403 (V1.0）
Table A-8 Terminal description
Symbol
PWR
GND
DATA+
DATA-
CLK+
CLK-
A+
A-
B+
B-
OA+
OA-
OB+
OB-
OA
OB
COM1
Function description
Encoder power
Encoder signal input terminal
5V differential crossover signal output
terminal
Open collector frequency-divided signal
output terminal
Expansion card
