P17.14
P17.15 Torque reference value
P17.16 Linear speed
P17.17–
P17.18
P17.19 AI1 input voltage
P17.20 AI2 input voltage
P17.21–
P17.25
P17.26 Duration of this run
Present step of simple
P17.27
Motor ASR controller
P17.28
Pole angle of open-loop
P17.29
Phase compensation of
P17.30
202403 (V1.0）
Name
bit1: RO1
bit2: RO2
bit3: RO3
Reserved -
Indicates the percentage of the
rated torque of the present motor,
displaying the torque reference.
Setting range: -300.0%–300.0% (of
the motor rated current)
0–65535
Reserved -
Displays the AI1 input signal.
Setting range: 0.00–10.00V
Displays the AI2 input signal.
Setting range: -10.00V–10.00V
Reserved -
Displays the duration of this run of
the VFD.
Setting range: 0–65535min
The function code is used to display
the present step of the simple PLC
PLC function.
Setting range: 0–15
Displays the ASR controller output
value as a percentage relative to the
rated motor torque under the vector
output control mode.
Setting range: -300.0%–300.0% (of
the motor rated current)
Displays the initial identification
angle of SM.
SM
Setting range: 0.0–360.0
Displays the phase compensation of
SM.
SM
Setting range: -180.0–180.0
Description
Function parameter list
Default Modify
- -
0.0% ●
0 ●
- -
0.00V ●
0.00V ●
- -
0min ●
0 ●
0.0% ●
0.0 ●
0.0 ●
