Goodrive390L Series Lift-Dedicated VFD
Function
code
P11.05 Current limit selection
Automatic current limit
P11.06
Frequency decrease
P11.07
ratio in current limiting
P11.08
Overload pre-alarm
P11.09
detection threshold
Overload pre-alarm
P11.10
detection time
P11.11–
P11.12
202403 (V1.0）
Name
During accelerated running, as the
load
acceleration rate of motor is lower
than that of output frequency. To
prevent
overcurrent
take the current limit measures.
Setting range: 0x00–0x11
Ones place: Current limit action
0: Invalid
1: Always valid
Tens place: Hardware current limit
overload alarm
0: Valid
1: Invalid
Setting range: 50.0–200.0% (of the
threshold rated VFD output current)
Setting range: 0.00–50.00Hz/s
Reserved -
If the VFD or motor output current is
larger than the overload pre-alarm
detection level (P11.09), and the
duration
pre-alarm detection time (P11.10),
overload pre-alarm signal will be
outputted.
Setting range: P11.11–200% (relative
value determined by the ones place
of P11.08)
Setting range: 0.1–3600.0s
Reserved -
Description
is too large, the
the VFD trip
during acceleration,
exceeds the
Function parameter list
Default Modify
actual
due to
0x00
For the G
type:
160.0%
For the P
type:
120.0%
10.00
Hz/s
-
Type G:
overload
150%
For the P
type:
120%
1.0s
-
◎
◎
◎
-
○
○
-
