Goodrive390L Series Lift-Dedicated VFD
Function
Communication-based
setting address
202403 (V1.0）
Address
0006H: Coast to stop
0007H: Fault reset
0008H: Jogging stop
Communication-based frequency setting (0–Fmax;
2001H
unit: 0.01 Hz)
PID reference (0–1000, in which 1000 corresponds
2002H
to 100.0%)
PID feedback (0–1000, in which 1000 corresponds
2003H
to 100.0%)
Torque setting (-3000–3000, in which 1000
2004H
corresponds to 100.0% of the motor rated current)
Upper limit setting of forward running frequency
2005H
(0–Fmax; unit: 0.01 Hz)
Upper limit setting of reverse running frequency
2006H
(0–Fmax; unit: 0.01Hz)
Upper limit of the electromotive torque (0–3000, in
2007H which 1000 corresponds to 100.0% of the motor
rated current)
Braking torque upper limit (0–3000, in which 1000
2008H
corresponds to 100.0% of the motor rated current)
Special CW
Bit0–1=00: Motor 1
Bit2=1 Enable speed/torque control switchover
=0: Disable speed/torque control
switchover
2009H
Bit3=1 Clear electricity consumption data
=0: Keep electricity consumption data
Bit4: =1 Enable pre-excitation =0: Disable
pre-excitation
Bit5: =1 Enable DC braking =0: Disable DC braking
Virtual input terminal command (0x000–0x3FF)
200AH Corresponding to the local
S10/S9/S8/S7/S6/S5/S4/S3/S2/S1
Virtual output terminal command (range: 0x00–
200BH 0x0F)
(corresponding to local RO3/RO2/RO1/Y1)
Voltage setting (used when V/F separation is
200CH
implemented)
Communication protocol
Data description
=01: Motor 2
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
