INVT Goodrive390L Series User Manual page 218

Goodrive390L Series Lift-Dedicated VFD
Function
code
P96.10–
P96.11
P96.12 Analog weighing input
P96.13 Pre-torque offset
P96.14 Drive-side gain
P96.15 Braking-side gain
AM open-loop start brake
P96.16
release frequency
P96.17 Brake closing delay
P96.18 Brake release delay
Brake feedback
P96.19
detection time
Brake fault action
P96.20
Contactor feedback
P96.21
detection time
Contactor fault action
P96.22
Contactor switch-off
P96.23
P96.24–
P96.28
P96.29 Stop braking frequency Setting range: 0.00–5.00Hz
P96.30
Current withdrawal time
P96.31
Enable light load
P96.32
direction search
Light-load direction
P96.33
detection time
202403 (V1.0）
Name
Reserved -
Setting range: 0–1
0: None
1: AI1
Setting range: 0.0–100.0%
Setting range: 0.000–7.000
Setting range: 0.000–7.000
Setting range: 0.00–5.00Hz
Setting range: 0.00–5.00s
Setting range: 0.00–5.00s
Setting range: 0.0–5.0s
Setting range: 0–1
0: Report a fault and stop
selection
1: Stop without reporting a fault
Setting range: 0.0–5.0s
Setting range: 0–1
0: Report a fault and stop
selection
1: Stop without reporting a fault
Setting range: 0.00–10.00s
delay
Reserved -
Stop delay Setting range: 0.00–5.00s
Setting range: 0.00–5.00s
after stop
Setting range: 0–2
0: Disable
1: Enable auto running
2: Enable to only provide running
direction
Setting range: 0.000–5.000s
Description
Function parameter list
Default Modify
- -
0 ◎
45.0% ○
2.000 ○
2.000 ○
0.00Hz ○
0.10s ◎
0.10s ◎
2.0s ◎
0 ◎
2.0s ◎
0 ◎
0.50s ◎
- -
0.40Hz ○
0.10s ◎
0.00s ◎
1 ◎
2.000s ◎
