Goodrive390L Series Lift-Dedicated VFD
Description

A request code is two bytes. Byte0 is the LSB, and Byte1 is the MSB. The manufacturer
defines the index 0x2100 and subindex 0x00 for the request codes.
the functions of the request codes.
Request
code
0
1
2
Modifying a parameter value [modifying the value only on both RAM and
4
A parameter address is two bytes. Byte2 is the LSB, and Byte3 is the MSB. It indicates the
address of the parameter to be read or modified.
Parameter address representation rules: The MSB is the hexadecimal form of the number
before the dot mark, and LSB is that of the number behind the dot mark. Take P11.05 as
an example, the number before the dot mark is 11, that is, the MSB of the parameter
address is 0×0B; and the number behind the dot mark is 05, that is, the LSB is 0×01.
Therefore, the function code address is 0×0B05.
Function
Name
code
Current limit
P11.05
selection
A piece of requested data is two bytes. Byte4 is the LSB, and Byte5 is the MSB. It indicates
the data to be modified. When the command is transmitted for reading data, the
requested data is not used.
Note: The data domain of PDO1 Rx must be six bytes. Otherwise, the VFD reports an
emergency packet.
202403 (V1.0）
Table 7-13 Request code
Reading a parameter value
Modifying a parameter value [modifying the value only on RAM]
Table 7-14 VFD parameter addresses
Description
0x00–0x11
Ones place: Current limit action
0: Invalid
1: Always valid
Tens place: Hardware current limit
overload alarm
0: Valid
1: Invalid
Function
No task.
EEPROM] (reserved)
Communication protocol
Table 7-13
Setting
Default Modify
range
0x00–0x11 0x00
describes
◎
93
