INVT Goodrive390L Series User Manual page 182

Goodrive390L Series Lift-Dedicated VFD
Function
code
Frequency display
P07.08
Rotational speed
P07.09
display coefficient
Linear speed display
P07.10
Rectifier bridge
P07.11
temperature
Inverter module
P07.12
temperature
Software version of MCU
P07.13
Software version of DSP
P07.14
VFD electricity
P07.15
consumption MSB
202403 (V1.0）
Name
state slowly)
Bit 1: Bus voltage (V on)
Bit2: Input terminal state
BIT3: Output terminal state
Bit 4: Reserved
Bit5: Reserved
Bit6: Reserved
Bit7: AI1 (V on)
Bit8: AI2 (V on)
Bit 9: Reserved
Bit 10: Reserved
Bit 11: Reserved
Bit 12: Reserved
Bit 13: Reserved
Bit14: Reserved
Setting range: 0.01–10.00
Display
coefficient
frequency *
Setting range: 0.1–999.9%
Mechanical rotation speed = 120 ×
(Displayed running frequency) ×
P07.09/(Number of motor pole pairs)
Setting range: 0.1–999.9%
Linear speed = (Mechanical rotation
coefficient
speed) ×
Setting range: -20.0–120.0℃
Setting range: -20.0–120.0℃
Setting range: 1.00–655.35
board
Setting range: 1.00–655.35
board
The function code is used to display
the electricity consumption of the
VFD.
VFD electricity consumption =
Description
frequency = Running
P07.08
P07.10
Function parameter list
Default Modify
1.00
100.0%
1.0%
0.0℃
0.0℃
Version
depended
Version
depended
0kWh
P07.15
○
○
○
●
●
●
●
●
