INVT Goodrive390L Series User Manual page 204

Goodrive390L Series Lift-Dedicated VFD
Function
code
P15.13
P15.14
P15.15
P15.16
P15.17
P15.18
P15.19
P15.20
P15.21 Sent PZD10
P15.22 Sent PZD11
202403 (V1.0）
Name
forward running frequency (0–Fmax,
unit: 0.01 Hz)
6: Setting of the upper limit of
reverse running frequency (0–Fmax,
unit: 0.01 Hz)
7: Upper limit of the electromotive
torque (0–3000, in which 1000
corresponds to 100.0% of the motor
rated current)
8: Upper limit of braking torque (0–
3000, in which 1000 corresponds to
100% of the motor rated current)
9. Virtual input terminal command
(range: 0x000–0x3FF, corresponding
to S10/S9/S8/S7/S6/S5/S4/S3/S2/S1)
10: Virtual output terminal
command (range: 0x00–0x0F,
corresponding to RO3/RO2/RO1/Y1)
11: Voltage setting (special for V/F
separation) (0–1000, in which 1000
corresponds to 100% of the motor
rated voltage)
12–18: Reserved
19: Function parameter mapping
(PZD2–PZD12 correspond to P14.49–
P14.59)
20–31: Reserved
Sent PZD2
Setting range: 0–31
Sent PZD3
0: Invalid
Sent PZD4
1: Running frequency (×100, Hz)
Sent PZD5
2: Set frequency (×100, Hz)
Sent PZD6 3: Bus voltage (*10, V)
Sent PZD7 4: Output voltage (×1, V)
5: Output current (×10, A)
Sent PZD8
6: Actual output torque (×10, %)
Sent PZD9
7: Actual output power (×10, %)
8: Rotation speed of running (×1,
Description
Function parameter list
Default Modify
0 ○
0 ○
0 ○
0 ○
0 ○
0 ○
0 ○
0 ○
0 ○
0 ○
