Goodrive270 series VFD for fan and pump
Field

3.6 Product ratings

VFD model
GD270-1R5-4(-C2)
GD270-2R2-4(-C2)
GD270-004-4(-C2)
GD270-5R5-4(-C2)
GD270-7R5-4(-C2)
GD270-011-4(-L1/-C2)
GD270-015-4(-L1/-C2)
GD270-018-4(-L1/-C2)
GD270-022-4(-L1/-C2)
GD270-030-4(-L1)(-C3)
GD270-037-4(-L1)(-C3)
GD270-045-4(-L1)(-C3)
GD270-055-4(-L1)(-C3)
GD270-075-4(-L1)(-C3)
GD270-090-4(-L1)(-C3)
GD270-110-4(-L1)(-C3)
GD270-132-4(-L1)(-C3)
GD270-160-4(-L1)
GD270-185-4(-L1)
GD270-200-4(-L1)
GD270-220-4(-Ln)
GD270-250-4(-Ln)
GD270-280-4(-Ln)
GD270-315-4(-Ln)
GD270-355-4(-Ln)
GD270-400-4-Ln
GD270-450-4-Ln
GD270-500-4-Ln
No. Field description
Table 3-1 Ratings for AC 3PH 380V models
Output power
1.5-132kW
C2: with built-in C2 filter, applicable to 1.5–22kW
models
C3: with built-in C3 filter, applicable to 30–132kW
models
Input current (A)
(kW)
1.5
2.2
4
5.5
7.5
11
15
18
22
30
37
45 108 (101)
55
75 177 (149)
90 200 (171)
110 240 (205)
132 278 (235)
160 310 (296)
185 335 (320)
200 385 (368)
220
250 465 (444)
280 540 (485)
315 605 (550)
355 655 (600)
400
450
500
-12-
Content
Output current
5 (5)
6 (6)
15 (15)
20 (20)
27 (27)
35 (35)
44 (44)
46 (46)
54 (54)
75 (56)
90 (69)
142 (117)
430 (411)
660
745
800
Product overview
(A)
3.7
5
9.5
13
17
25
32
38
45
60
75
92
115
150
180
215
250
305
330
380
425
460
530
600
650
720
820
860
