Group P17—Status viewing
Function
code
P17.00
P17.01 Output speed
P17.02 Ramp reference speed
P17.03 Output voltage
P17.04 Output current
P17.05 Motor rotation speed
P17.06 Torque current
P17.07 Exciting current
202403 (V1.0）
Name
Setting range: 0x0000–0xFFFF
address 4
Reserved -
Name
Displays the present set speed of the
VFD.
Set speed
Setting
(rated lift speed)
Displays the present output speed of
the VFD.
Setting
(rated lift speed)
Displays the present ramp reference
speed of the VFD.
Setting
(rated lift speed)
Displays the present output voltage
of the VFD.
Setting range: 0–1200V
Displays the valid value of present
output current of the VFD.
Setting range: 0.0–5000.0A
The function code is used to display
the present motor speed.
Setting range: 0–65535rpm
The function code is used to display
the present torque current of the
VFD.
Setting range: -3000.0–3000.0A
The function code is used to display
Description
Description
range: 0.000m/s–P00.06
range: 0.000m/s–P00.06
range: 0.000m/s–P00.06
Function parameter list
Default Modify
0x0000 ○
- -
Default Modify
0.000m/s ●
0.000m/s ●
0.000m/s ●
0V ●
0.0A ●
0rpm ●
0.0A ●
0.0A ●
